EZ Gate

The IVEC E-Z Gate provides automatic, electronically controlled airflow management within central ventilation, dust collection, or fume extraction systems. Each gate operates through a high-torque, intelligent actuator that opens or closes the internal blade based on system demand or sensor input. When paired with IVEC Smart Controls, the gates dynamically balance airflow across the network, ensuring each workstation receives optimal suction while minimizing fan energy consumption. The gate’s precision-engineered blade and seal assembly eliminates pinching and air leakage, ensuring a reliable seal up to 100” W.C. The system can be mounted either horizontally or vertically and is compatible with both new and retrofit installations. Typical configurations and options include:

• Blade positioned 100% out of the airstream for unrestricted flow
• High-pressure duct seal rated for 100" W.C.
• Galvanized or stainless-steel body construction
• Connection types: flanged, rolled-lip adapter, or raw edge
• Overload protection with manual override capability
• Optional 4-20 mA modulating control for advanced automation
• Compatible with IVEC Smart Controller or any dry-contact input system

Each E-Z Gate is precision-welded from heavy-gauge galvanized or stainless steel and fitted with a reinforced body to maintain seal integrity under high static pressures. The compact actuator housing contains an intelligent electric motor with positional feedback and thermal overload protection. All gates feature an M12 quick-connect interface and are available in multiple duct sizes, including 4"–24" diameters. The unit’s redesigned frame is 30% smaller and 10% lighter than earlier models, reducing installation load while doubling structural strength. Sealing surfaces use high-temperature-rated elastomers for long-term reliability in continuous-duty applications. The actuator carries a 5-year warranty for extended lifecycle confidence.

• Energy Efficiency: Achieve up to 50–80% energy savings when paired with IVEC Smart Controls.
• Fast Response: 40% faster actuation time ensures optimal capture during rapid process changes.
• Compact Strength: Twice as strong yet 30% smaller than comparable motorized blast gates.
• Maintenance-Free: No compressed air, no external power supply, and no moving parts in the airstream.
• Flexible Installation: Works with both flanged and rolled-lip ducting; mounts vertically or horizontally.
• Smart Integration: Plug-and-play compatibility with IVEC Automation for true “exhaust on demand.”
• Long Life: Heavy-duty welded body and high-torque actuator rated for industrial environments.
• Safe and Reliable: Overload protection, manual override, and NEMA 4 actuator housing.

Top 5 contaminants/processes/applications:

• Industrial ventilation systems
• Dust and fume extraction networks
• Smart factory automation
• Multi-duct installations
• Energy-efficient retrofit upgrades
• Automotive and Aerospace Fabrication
• Powder Coating and Finishing Lines
• Educational and Vocational Training Shops

Don't see your contaminants? Give us a call at 1-888-862-5356 or email us at sales@lev-co.com!

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.
