PATRIOT-TOR
Overview
- 12" Diesel stack exhaust capture hood
- 12" diamete 17' long high temp extraction arm mounted on 24" swiveling inlet extension
- 10 Hp 575V Motor/Fan
- Electrical option for P2D2-R3. 10HP @ 575V/3/60. Includes:
- VFD rated for 10HP @ 575V
- Nema 4 VFD enclosure
- 60A Fuse Switch (complete)
- Twist lock weld plug rated for 575V
- 50' of cabtire
- Low voltage HIGH/LOW/OFF switch
- Running light
- Pre-assembly of all electrical components, wired & installed with mounting brackets
- CSA approved
- Layflat hose reel/storage
Specificiations
Shipping Specificiations
| Shipping Weight | 400.0 lbs. |
| Shipping Length | 36 in. |
| Shipping Width | 36 in. |
| Shipping Height | 96 in. |
The PATRIOT is a heavy-duty portable Local Exhaust Ventilation system for almost any heavy industrial application.
With IP66 controls and a chassis fabricated from combination satin coat steel and powder-coated for additional protection, the PATRIOT is ideal for outdoor environments. The unit transports well to and from job sites, under the garage door, or through a door/wall exhaust.
The portable, easy to position, and quick set-up with tool-less "quick-connect" hoses and accessories allow the PATRIOT to be deployed and operated by a single person.
This Plug and Go unit is designed to be energy efficient, by eliminating peak electrical charges and wasted heat. It can also be set to an Ultra-Quiet mode, by controlling the VFD to the noise level, frequency, and flow rate.
This unit has a typical flow rate between 700CFM and 7000CFM.
Main options include:
- Variety of Capture and Receiving Hoods
- Variety of Hoses (EG: Chemical, ESD, Abrasion, Hi-temp>2000 C)
- Variable Frequency Drive
- Fan, Light, and Electrical Accessories
- Overhead Stack Adapters
- Casters
CONSTRUCTION
- Portable and Easy to Position - (6) Heavy-duty casters (2 straight, 4 swivel)
- “All-In-One” Design – “on-cart” storage for all hoses, hoods, etc.
- All Steel Heavy Duty Construction - 3/14/16 ga.
- Spark Proof Design and Construction
- Environmentally Friendly VFD Control – Variable exhaust flow ensures energy-saving efficiency
- Hose Storage Tubes – Ensure the hoses will last
- 8''/10'' Ø Hoses
KEY CRITERA
- Portable: The all-in-one design makes the unit easily stored with all attachments, saving space otherwise taken up by the accessories
- Quick Setup: Tool-less quick connect hoses and accessories
- Adjustable Velocity: Allows you to set up the unit for any application, and saves energy in scenarios with excess airflow
- Single Person Operation: The system is easily operated individually, maximizing production
- Weatherproof: Powder-coated chassis, and IP66 controls shield the unit from exposure to elements
SUITABLE FOR
- Diesel Exhaust Fumes
- Welding Fumes
- Explosive Gasses
- Arc Air Gouging
- Flame Cutting
- Portable Vehicle Exhaust Learn More
