Model

05-015

Image for SLEDGEHAMMER.jpg

Sledgehammer - 2'D X 3'W

Sledgehammer © - A series of downdraft tables designed to be a dual-purpose workstation and extraction solution.

These tables draw contaminants from the source away from workers’ breathing zone without hindering movement. This unit features a max flow rate of 1200 CFM

Function:

Heavy-duty Downdraft table that provides the most durable ¼” steel plate work surface (36” X 24”) on the market.
The Sledgehammer © is equipped with Jet-Pulse Cleaning that allows simple cleaning of the filter, which reduces filter costs dramatically*.

Available with:
  • VFD Options
  • Preventative Maintenance Pressure Gauges

Construction:

These pre-engineered, ‘’Plug and Play’’ downdraft tables come complete with the following:
  • Fan Capacity: 1200 CFM (2000 m3/h)
  • “Nano Fiber” filter cartridge, 99.9 % efficient @ 0.5 Micron
  • Direct drive fan coupled with Non-Sparking Aluminum Impeller
  • 1.5 HP (1.1 KW) 120V/1/60 TEFC Direct Drive class II motor
  • ’Plug & Play’ Design includes easy maneuverable wheels, Motor starter, overload protection, 12’ cord and plug)
  • Flow Controller allows the flow rate to be reduced eliminating the change of porosity
  • Internal dust tray
  • 1/4" steel plate work surface 36” X 24” (900 X600 mm)
  • 5 stage spark arrestance package including Deflection grates, 2 - Spark absorption trays (Fill with water and/or sand – by others), Baffles, expansion chamber and optional plasma cutting spark arresting surface
  • Welding gun/ground clamp holder/connection
  • Working booth design with back and side walls
  • Jet-Pulse pneumatic filter cleaning system
  • Low height design that can be easily raised to suit almost every working height

Shipping Dimensions and Weight:

Main System Part # Height x Width x Depth Weight
P-541 13"H x 16"W x 16"D 10 lbs
Filter Wrap Around 12"H x 2"W x 52"D 2 lbs
DF-SCF-24-30-115 53"H x 31.5"W x 47"D 260 lbs

Key Buying Criteria:

  • 115 Volt: Ability to plug into any standard circuit, reducing installation costs
  • Filter Cleaning System:Ability to clean by air to remove the contaminant from the filter without taking the filter out of the unit, lowering operation costs
  • Integrated spark trap with water tray: Ability to pre-separate the spark before the main filter, which reduces the risk of fire
  • Flame, melt and deform proof steel construction: Avoid high cost of replacement plastic parts
  • Small foot print: Ability to maneuver with ease especially in narrow areas, saving space in the production area

Suitable For:

Top 5 contaminants/processes/applications:

  • VOC Fumes
  • Gases
  • Composite Dust
  • Welding Gases
  • Grinding Particles
Don't see your contaminants? Give us a call! 1-888-862-5356 or Click our instant chatbox.

IMPORTANT: For your Health and Safety, make sure to talk to an application engineer before purchasing.
Part # Qty Description
DF-SCF-24-30-115 Sledgehammer Downdraft Table, self-cleaning *100% washable replacement filter cartridge with 45% more surface area and 15% higher flow rate.
*All steel construction (no plastic to deform or melt)
*Smallest footprint of any unit on the market (22 x 25 = 3.8ft2)
*Powerful 1.1 KW (1.5HP) motor 115V/1/60 UL / CSA *Complete with Motor starter, overload protection, plug and switch - Ready to use
*Dual Stage spark trap
*Cleanable filter (with water or compressed air)* *Complete with integrated filter cleaning system **AS PER CANADIAN LAW; this unit is electrically approved by CSA/ESA field evaluation.
Part # Qty Description
Filter Wrap Around Filter Wrap Around.
SCF-541 Main Filter for ''''Self Cleaning" filter units (RF-SCF, CF-ECO, Sledge-hammer, MF-ECO & WF-SCF)

Frequently bought together these options:

Part # Qty Description
VFD-KIT-1HP-115-230-3 1HP 120-240V Hybrid VFD 1 Phase In, 230V 3 Phase Output 60Hz complete with:
  • VFD NEMA 4
  • 1 HP Motor
  • Able to support HP lower than 1HP
  • Wiring
  • Labor
  • Re-certification
  • PLEASE NOTE: this kit is only required when upgrading a 120V system with a VFD
VFD-KIT-2HP-115-230-3 2HP 120-240V Hybrid VFD 1 Phase In, 230V 3 Phase Output 60Hz complete with:
  • VFD NEMA 4
  • 2 HP Motor
  • Able to support lower HP between 1HP - 2HP
  • Wiring
  • Labor
  • Re-certification
  • PLEASE NOTE: this kit is only required when upgrading a 120 or 220/1/60 V system with a VFD
VFD-KIT-3HP-220-230-3 3HP 240V Hybrid VFD 1 Phase In, 230V 3 Phase Output 60Hz complete with:
  • VFD NEMA 4
  • 3 HP Motor
  • Able to support lower HP between 2HP - 3HP
  • Wiring
  • Labor
  • Re-certification
  • PLEASE NOTE: this kit is only required when upgrading a 120V system with a VFD
Part # Qty Description
MF-LGT Dust-tight light for Sledgehammer series Down Draft Table
MF-SH-CSI Insert for chopsaw
