F480

$49,475.30 CAD

Overview

Standard Product
Out of Stock
12,000 cfm industrial air cleaner with (4) 4 deep, 30% pleated prefilters, (4) 65% bag filters, 120 sq.ft. of media each, and a 15 HP TEFC motor. 208-230/460/575/3/60Hz (38/19 amps). 86 dBA.

Specificiations


Shipping Specificiations

Shipping Weight 1,430.0 lbs.
Shipping Length 82.5 in.
Shipping Width 56 in.
Shipping Height 66 in.
Model 10-005: F480 - 12,000 CFM
F480 models are designed to collect airborne dust, smoke, oil mist, oil smoke, and other atmospheric pollutants in industrial plants, shops, schools, and factories.

High-efficiency multi-stage filtration. This model features a flow rate of 12000 CFM.

  • Largest filtration, smallest dimensions
  • Multiple configurations makes installation possible in congested/tight areas

FUNCTION
The F480 ducted Industrial Air Cleaner comes standard with (4) 4” (100mm) deep 30% pleated pre-filter, (4) 65% bag filter, 96ft² of media each, and a 15 HP TEFC motor 208-230/460/575/3/60Hz. The fan is included inside the unit.

These units are complete, packaged air filter units that can easily be attached to ductwork and pickup hoses for at-the-source collection of pollutants.

There are multiple filter configurations available featuring washable and/or disposable filters. The filter unit can be upgraded to have different filter and fan packages to suit various applications and contaminants.

Main Options:
  • Fan and Motor Upgrades
  • Filter Options
  • Pressure Gauges
  • Variable Frequency Drives
  • Sound Attenuation

CONSTRUCTION
  • 16 ga. steel cabinet with powder-coat finish
  • Ultra-Seal® filter sealing system
  • Side access door to filters
  • Internal belt drive
  • Ball bearing Class II blower with fixed speed pulleys
  • 4-way adjustable airfoil blade exhaust grille and
  • Motor wired to external junction box

KEY CRITERA
  • Class II Belt-Drive Blower: Higher static pressure, longer filter life and greater reliability; spark-resistant.
  • Non-Electrostatic Operation: High reliability, low maintenance.
  • Ultra-Seal® Filter Mounting: Eliminates contaminant bypass of filters.
  • High-Efficiency Filter Media: Provides maximum effectiveness; low air-to-cloth ratio extends cycles between filter changes; filter chugs easily without tools.
  • Prewired to Junction Box: For fast, easy installation.

SUITABLE FOR
Top 5 contaminants/processes/applications:

  • Oil Mist
  • Wood Dust
  • Oil Smoke
  • Plastic Fumes
  • Cannabis Dust
